Tackling Hydrogen Permeation

🌟 Such failure mechanism caused as a result of sensing membrane
🌟 Oil-filled sensors employ very thin isolation diaphragm typically with 0.025mm thickness
🌟 Hydrogen "plus" ions will escape through diaphragm with such thickness
🌟 As thickness increases (say 0.18mm) such permeation tends to stop subject to the operating temperature

🎡 Diaphragm Membrane of Avery Instrument Hydrogen Pressure Sensor

Application - PEM Fuel Cell for Vehicles

🌟 MEMs-Based Bulk Silicon Piezo-Resistive Pressure Sensing
🌟 Sensors be used for measuring tank and hydrogen pressures before release into fuel cell
🌟 The one-piece 316L sensing element is capable to pass all standards for hydrogen pressure cycles and burst pressure requirements.
🌟 Meet environmental conditions such as high pressure wash-down, salt water submersion, dust conditions, shock and vibration.
🌟 Electrical conditions simulated for up to 300V/m of EMI protection.

Application - Hydrogen Storage

🌟 Due to the small size of hydrogen ions, correct material compatibility and construction of components exposed to hydrogen is critical.
🌟 Our sensors able to eliminate leak paths common to other pressure sensor designs
🌟 Sensing elements applicable to ultra-high pressure ranges common to hydrogen storage
🌟 Storage tanks be smaller by compressing hydrogen at higher pressures, creating lighter and mobile system

保修条款

🔮 工艺 - Avery Instrument Limited（AVERY）的压力传感器向原始购买者提供有限的一年保修期。AVERY将免费更换或修理任何有缺陷的传感器。此保修不适用于已经被修改、滥用、忽视或安装在应用超过已发布额定值的单位；标签丢失、损坏或在退还时无法辨认的情况。
安装/应用 - 购买者负责传感器与介质的兼容性、功能适用性以及正确的安装。
